MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards

MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
Save: 2200৳
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard | PRO Series Motherboards
  • Discount Price:
    25,599৳
  • Regular Price:
    27,799৳
  • Stock:
    In Stock
  • Brand: MSI
  • Model:
    PRO B860M-A WIFI

Payment Options

Key Features

  • Chipset - INTEL B860
  • Form Factor - Micro- ATX
  • Socket - LGA 1851
  • LAN - Realtek 8126 5Gbps
অনলাইনে অর্ডার করতে হলে, পণ্য ভেদে নির্দিষ্ট পরিমাণ টাকা অগ্রিম প্রধান করতে হবে। প্রোডাক্টের অবশিষ্ট টাকা, ক্যাশ অন ডেলিভারিতে পরিশোধ করবেন। প্রোডাক্ট স্টক অথবা দাম সংক্রান্ত যেকোনো বিষয়ে তথ্য জানতে আমাদেরকে কল করুন অথবা আমাদের হোয়াটসঅ্যাপে এ যোগাযোগ করুন।
Specification
Basic Information
Supported CPU Supports Intel Core Ultra Processors (Series 2)
Chipset INTEL B860
Form Factor Micro- ATX
Audio Realtek ALC897 Codec 7.1-Channel High Definition Audio
Expansion Slots
PCI 4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
M.2 Socket Total M.2 Slots: 2 1 × M.2 PCIe 5.0 x4 (CPU lane, NVMe SSD) 1 × M.2 PCIe 4.0 x4 (Chipset lane, NVMe SSD)
Graphics
Graphics Integrated Graphics Support: Depends on CPU with integrated GPU Video Output: 1 × HDMI 2.1 (Up to 4K @ 60Hz; CPU dependent) Expansion Graphics Support: 1 × PCIe 5.0 x16 slot for dedicated graphics card Multi-Display Support: CPU dependent
Memory
Type DDR5
Slots 4x PCI-E x16 slot PCI_E1 Gen PCIe 5.0 supports up to x16 (From CPU) PCI_E2 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E3 Gen PCIe 4.0 supports up to x1 (From Chipset) PCI_E4 Gen PCIe 4.0 supports up to x4 (From Chipset)
Supported Memory 4x DDR5 UDIMM, Maximum Memory Capacity 256GB Memory Support 8600 - 6400 (OC) MT/s / 6400 - 4800 (JEDEC) MT/s Max. overclocking frequency: • 1DPC 1R Max speed up to 8600+ MT/s • 1DPC 2R Max speed up to 7200+ MT/s • 2DPC 1R Max speed up to 4800+ MT/s • 2DPC 2R Max speed up to 4800+ MT/s Supports Intel® POR Speed and JEDEC Speed Supports Memory Overclocking and Intel® XMP 3.0 Supports Dual-Controller Dual-Channel mode Supports Non-ECC, Un-buffered memory Supports CUDIMM
Maximum Memory Maximum Capacity: 192GB
Connector & Ports
Wireless Communication module Intel Wi-Fi 7 The Wireless module is pre-installed in the M.2 (Key-E) slot Supports MU-MIMO TX/RX, 2.4GHz / 5GHz / 6GHz (320MHz) up to 5.8Gbps Supports 802.11 a/ b/ g/ n/ ac/ ax/ be
HDMI 1x HDMI Support HDMI 2.1, maximum resolution of 4K 60Hz
USB (s) 2x USB 2.0 (Rear) 4x USB 2.0 (Front) 2x USB 5Gbps Type A (Rear) 1x USB 5Gbps Type C (Rear) 4x USB 5Gbps Type A (Front) 1x USB 10Gbps Type A (Rear) 1x USB 10Gbps Type C (Front)
LAN Port (s) Realtek 8126 5Gbps LAN
Internal I/O Ports 1x Thunderbolt5 card connector(JTBT5, support RTD3) 1x Power Connector(ATX_PWR) 2x Power Connector(CPU_PWR) 1x Power Connector(PCIE_PWR 8pin) 1x CPU Fan 1x Combo Fan (Pump_Sys Fan) 3x System Fan 2x Front Panel (JFP) 1x Chassis Intrusion (JCI) 1x Front Audio (JAUD) 1x Com Port (JCOM) 1x Tuning Controller connector(JDASH) 2x Addressable V2 RGB LED connector (JARGB_V2) 1x RGB LED connector(JRGB) 1x TPM pin header(Support TPM 2.0) 4x USB 2.0 ports 4x USB 5Gbps Type A ports 1x USB 10Gbps Type C ports
Warranty Information
Manufacturing Warranty 3 years
Description

MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard in Bangladesh

MSI PRO B860M-A WIFI LGA1851 Micro ATX Motherboard is a versatile and high-performance motherboard designed for professionals and enthusiasts, now available at Tech Land BD in Bangladesh. Built to support the latest Intel Core Ultra Processors (Series 2) on the LGA 1851 socket, this Micro ATX motherboard combines power and efficiency with its Intel B860 chipset. It features four DDR5 UDIMM slots, supporting up to 256GB of memory with speeds ranging from 4800 MT/s (JEDEC) to 8600 MT/s (overclocked), and Intel® XMP 3.0 support for enhanced performance. The motherboard offers excellent connectivity options, including Intel Wi-Fi 7 with speeds up to 5.8Gbps, a Realtek 8126 5Gbps LAN port, and a Thunderbolt 4 USB Type-C port supporting DisplayPort 2.1 for resolutions up to 8K 60Hz. It also includes multiple display outputs, such as HDMI 2.1 (4K 60Hz) and DisplayPort 1.4 (4K 60Hz). Storage options are robust, with support for multiple M.2 and SATA devices, ensuring ample space for your data. The Realtek ALC897 codec delivers 7.1-channel high-definition audio, enhancing your multimedia experience. Despite its compact Micro ATX form factor, it provides extensive expansion options, including four PCIe slots and multiple USB ports (including USB 10Gbps). Backed by a 3-year warranty, the MSI PRO B860M-A WIFI ensures reliability and durability for your professional or gaming setup. Visit ONE STOP SOLUTION to purchase this feature-rich motherboard and elevate your PC build.


What processors are compatible with the MSI PRO B860M-A WIFI motherboard?

The motherboard supports Intel Core Ultra Processors (Series 2) and is designed for the LGA 1851 socket.


What type of memory does this motherboard support, and what is its maximum capacity?

It supports DDR5 UDIMM memory with a maximum capacity of 256GB and speeds ranging from 4800 MT/s (JEDEC) to 8600 MT/s (overclocked), with Intel® XMP 3.0 support for enhanced performance.


Does the motherboard support Wi-Fi 7, and what are its networking capabilities?

Yes, it features Intel Wi-Fi 7 with support for 2.4GHz, 5GHz, and 6GHz bands, offering speeds up to 5.8Gbps, along with a Realtek 8126 5Gbps LAN port.
