MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard

MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
Save: 2000৳
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard
  • Discount Price:
    18,899৳
  • Regular Price:
    20,899৳
  • Stock:
    In Stock
  • Brand: MSI
  • Model:
    PRO B840M-P WIFI6E
Based on 0 reviews. - Write a review

Payment Options

Buy Now
Buy Now Add to Compare
Add to Wish List Compare this Product

Key Features

  • Model: PRO B840M-P WIFI6E
  • Supported CPU: AMD Ryzen 9000/ 8000/ 7000 Series for Socket AM5
  • Supported RAM: 4x DDR5 UDIMM, Up to 8000 (OC) Mhz, Max. 256GB
  • Graphics Output: 1x HDMI 2.1, maximum resolution of 4K 60Hz
  • Features: 2x M.2 Slot, Realtek 8125D 2.5G LAN, Wi-Fi 6E, Bluetooth 5.3
View more info
অনলাইনে অর্ডার করতে হলে, পণ্য ভেদে নির্দিষ্ট পরিমাণ টাকা অগ্রিম প্রধান করতে হবে। প্রোডাক্টের অবশিষ্ট টাকা, ক্যাশ অন ডেলিভারিতে পরিশোধ করবেন। প্রোডাক্ট স্টক অথবা দাম সংক্রান্ত যেকোনো বিষয়ে তথ্য জানতে আমাদেরকে কল করুন অথবা আমাদের হোয়াটসঅ্যাপে এ যোগাযোগ করুন।
Specification
Technical Specifications
Form Factor mATX
243.84mmx243.84mm
Basic Information
Supported CPU Supports AMD Ryzen 9000/ 8000/ 7000 Series Desktop Processors
Socket AM5
Chipset AMD B840
Audio Realtek ALC897
7.1-Channel High Definition Audio
BIOS Flash BIOS Button
Expansion Slots
PCI 1x PCI-E x16 slot
1x PCI-E x1 slot
PCI_E1 Gen PCIe 4.0 supports up to x16 (From CPU)
PCI_E2 Gen PCIe 3.0 supports up to x1 (From Chipset)
PCI_E1 slot
• Supports PCIe 4.0 x16 (For Ryzen™ 9000/ 7000 Series processors)
• Supports PCIe 4.0 x8 (For Ryzen™ 8700/ 8600/ 8400 Series processors)
• Supports PCIe 4.0 x4 (For Ryzen™ 8500/ 8300 Series processors)
M.2 Socket 2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M2_2 slot
• Supports up to PCIe 4.0 x4
• Supports up to PCIe 4.0 x2 (For Ryzen™ 8500/ 8300 Series processors)
Graphics
Graphics 1x HDMI
Support HDMITM 2.1, maximum resolution of 4K 60Hz
Memory
Type DDR5
Slots 4x UDIMM
Supported Memory Memory Support DDR5 8000 - 5600 (OC) MT/s / 5600 - 4800 (JEDEC) MT/s
Ryzen 9000 Series Processors max. overclocking frequency:
• 1DPC 1R Max speed up to 8000+ MT/s
• 1DPC 2R Max speed up to 6400+ MT/s
• 2DPC 1R Max speed up to 6400+ MT/s
• 2DPC 2R Max speed up to 5600+ MT/s
Supports AMD POR Speed and JEDEC Speed
Supports Memory Overclocking and AMD EXPO
Supports Dual-Channel mode
Supports Non-ECC, Un-buffered memory
Supports CUDIMM, Clock Driver bypass mode only
Maximum Memory 256GB
Connector & Ports
Audio 1x Front Audio (JAUD)
Wireless Communication module Wi-Fi 6E
The Wireless module is pre-installed in the M.2 (Key-E) slot
Supports MU-MIMO TX/RX, 2.4GHz/ 5GHz/ 6GHz (160MHz) up to 2.4Gbps
Supports 802.11 a/ b/ g/ n/ ac/ ax
Supports Bluetooth 5.3, FIPS, FISMA
HDMI 1x HDMI
USB (s) 4x USB 2.0 (Rear)
4x USB 2.0 (Front)
2x USB 5Gbps Type A (Rear)
2x USB 5Gbps Type A (Front)
1x USB 5Gbps Type C (Front)
1x USB 10Gbps Type A (Rear)
1x USB 10Gbps Type C (Rear)
LAN Port (s) Realtek 8125D 2.5G LAN
Supported Storage 2x M.2
M.2_1 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
M.2_2 Source (From CPU) supports up to PCIe 4.0 x4 , supports 2280/2260 devices
4x SATA 6G
M2_2 slot
• Supports up to PCIe 4.0 x4
• Supports up to PCIe 4.0 x2 (For Ryzen 8500/ 8300 Series processors)
RAID Supports RAID 0, RAID 1, and RAID 10 for SATA storage devices
Supports RAID 0 and RAID 1 for M.2 NVMe storage devices
Internal I/O Ports 1x Power Connector(ATX_PWR)
1x Power Connector(CPU_PWR)
1x CPU Fan
1x Combo Fan (Pump_Sys Fan)
3x System Fan
2x Front Panel (JFP)
1x Chassis Intrusion (JCI)
1x Front Audio (JAUD)
1x Com Port (JCOM)
1x Tuning Controller connector(JDASH
3x Addressable V2 RGB LED connector (JARGB_V2)
1x RGB LED connector(JRGB)
1x TPM pin header(Support TPM 2.0)
4x USB 2.0 ports
2x USB 5Gbps Type A ports
1x USB 5Gbps Type C ports
TPM (Trusted Platform Module ) 1x TPM pin header(Support TPM 2.0)
Others
Special Features 4x EZ Debug LED
1x EZ Memory Detection LED
Warranty Information
Warranty 3 Years
Description

MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard


The MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard is engineered for users who want next-generation performance in a compact mATX form. Powered by the AM5 socket, this board supports the latest AMD Ryzen 7000 series processors, delivering outstanding speed and multitasking capabilities. With WiFi 6E and high-speed 2.5G LAN, you get ultra-fast, stable networking for gaming, streaming, or productivity.

Its DDR5 memory support ensures improved bandwidth and reduced latency, while the enhanced power delivery system guarantees consistent performance even under intensive workloads. The motherboard also features PCIe Gen4 support, M.2 slots with Shield Frozr, and advanced cooling solutions to maintain peak efficiency. Whether you're building a gaming PC or a professional workstation, the TechFusion B840M Matrix offers durability, reliability, and modern features at a great value.



MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard – Next-Gen AM5 Motherboard for Performance Builders

Looking to build a powerful and future-ready PC? Buy the MSI PRO B840M-P WIFI6E AM5 Micro ATX Motherboard from our store one-stop solution for authentic PC hardware in Bangladesh. We ensure competitive pricing, fast delivery, and dependable after-sales support so you can shop with confidence.
